Nova Mini Zone Control Kit
Part number: C535K
Overview
The iZone Nova climate control zone kit features a Power DC connection to the 7″ Nova wall controller. The kit includes a Smart Hub (COCBH) for integrated Wi-Fi connectivity, enabling seamless mobile control and remote diagnostics for installers and end users.
Installation Guides
Standard installation
Installation videos
- Step 1: Parts VIDEO
- Step 2: Wiring VIDEO
- Step 3: CPU installation VIDEO
- Step 4: Smart Hub installation VIDEO
- Step 5: Touch screen installation VIDEO
- Step 6: Power on VIDEO
- Step 7: setup wizard VIDEO
- Step 8: Nova pairing sensors VIDEO
- Step 9: Link homeowner to new system VIDEO
Advanced installation
- Install multiple Nova screens
- Install multple AC units
- Install a VRF system
- How to extend zones (9-14 zones)
- Hardwire CPU and Smart Hub
User Guides
Parts Included
| Part | Description |
|---|---|
| C225 | 8-zone CPU |
| CT24ACE | 24Vac CPU power supply |
| COCBH | Smart Hub |
| CCASSW | Nova 7" screen with DC connection |
| CDTS | In-duct temperature sensor |
| CTDC12 | 12m Nova power supply |
Support
- For troubleshooting, refer to the Parts Included section.
- For frequently asked questions (FAQs), visit the Support Zone.
- For design guidance and best practices, see the How to Guides.
Specifications
| Entry | Description |
|---|---|
| Dimensions | 320W x 140H x 300D mm |
| Weight | 3.120kg |
