Nova Mini CAT zone control system
Part number: C536K
Overview
The iZone Nova climate control zone kit features a dedicated CAT5 connection between the Screen Link Module (CSL) and a 7″ Nova wall controller. The kit includes a Smart Hub (COCBH) for integrated Wi-Fi connectivity, enabling seamless mobile control and remote diagnostics for installers and end users.
Installation Guides
Standard installation
📄 Quick Install Guide
🔗 Online Installation Guide
🎬 Nova with CAT5 — no zone temp sensors (return air)
🎬 Nova with CAT5 — zone temp sensors
🎬 Link homeowner to new system
Advanced installation
- Install multiple Nova screens
- Install multple AC indoor/outdoor units
- Install a VRF system
- How to add more zones (9-14 zones)
- Hardwire CPU and Smart Hub
User Guides
📄 Nova user manual
🔗 iZone Home mobile interface
Parts Included
| Part | Description |
|---|---|
| C225 | 8-zone CPU |
| CT24ACE | 24Vac CPU power supply |
| CSL | Screen Link Module |
| COCBH | Smart Hub |
| CCASSWE | Nova 7" screen with CAT5 connection |
| CDTS | In-duct temperature sensor |
| CFC12S | 12m CAT5 cable |
Support
- For troubleshooting and frequently asked questions, refer to each individual part within Parts Included
- For design guides, see How to Guides
Specifications
| Entry | Description |
|---|---|
| Dimensions | 320W x 140H x 300D mm |
| Weight | 3.120kg |
