Nimble Zone Control Kit
Part number: C110K
Overview
Entry level open/close zone control kit using the Nimble Master Controller (C110MC) and Nimble Wall Controller (C110WC). No temperature sensor support — zones are open/close only. No AC unit interface module included.
Installation Guides
User Guides
Parts Included
| Part | Description |
|---|---|
| C110MC | Nimble Master Controller |
| C110WC | Nimble Wall Controller |
| CT24ACE | 24VAC CPU power supply |
| CFC12S | 12m CAT5 cable |
Support
- For troubleshooting, refer to the Parts Included section.
- For frequently asked questions (FAQs), visit the Support Zone.
- For design guidance and best practices, see the How to Guides.
Specifications
| Entry | Description |
|---|---|
| Dimensions | 290W x 145H x 255D mm |
| Weight | 3.255kg |
